530 Chain Motorcycle Budget-friendly Choice
This 530 Chain Motorcycle is made of SCM420 chromium molybdenum alloy steel with an average tensile strength of more than 40 kN. It is specially designed to provide excellent fatigue resistance and wear resistance for large displacement locomotives above 400cc. Motomaxsfr is a source manufacturer with its own heat treatment workshop, strictly implementing ISO 9001 standards and eliminating traders, providing you with an absolute advantage of batch ex-factory quotation and highly flexible production scheduling.
15,875 мм
Pitch
9.53mm
Ширина ролика
more than 42 kN
Прочность на разрыв
30 chromium manganese titanium
Pin shaft material
2.40mm
Толщина пластины цепи
Х-кольцо
Sealing form
600 to 1000cc
Applicable displacement
1.05kg per meter
Average weight
riveted connection
Joint type
Our products
The 530 Chain Motorcycle is the 1 precision power transmission component made of high-quality alloy steel. It efficiently transmits engine torque to the rear wheels by meshing with sprockets. It is suitable for high-performance street cars and off-road motorcycles.
530 Chain Motorcycle characteristics
4 riveting pin shaft technology
The unique four-sided riveting process is adopted to increase the flared diameter of the pin shaft head by 0.3mm, so that the thrust load bearing capacity of the chain link side plate is increased by 25%, and the risk of chain detachment under high-speed operation is effectively prevented.
Vacuum injection of solid lubricating oil
Before leaving the factory, high-viscosity and high-temperature resistant grease is injected through vacuum environment to ensure that the grease penetrates into the area of 100% of the clearance between pin shaft and sleeve. Compared with ordinary oil immersion process, the initial running-in wear of the chain is reduced by 60%.
Pre-stretch anti-fatigue treatment
Before leaving the factory, all chains are pre-stretched by 1/3 breaking load, which eliminates the initial inelastic deformation of the material, controls the initial elongation after loading within 0.1%, and greatly reduces the adjustment frequency.
High precision seamless sleeve
Abandon the rolled sleeve, the seamless sleeve formed by cold extrusion is adopted, and the cylindricity tolerance is controlled within 0.01mm to ensure smooth meshing with the sprocket and reduce the operating noise by 3 to 5 decibels.
X-ring long-lasting oil lock
Equipped with high-quality nitrile rubber X-ring, it uses four contact points to form a double sealing barrier. Compared with traditional O-ring, it can lock 40% more lubricating oil and block dirt from the outside.
Ultra wide displacement applicability
With extremely high tensile strength from 42kN to 46kN, the 530 chain is not only suitable for conventional 500cc models, but also can stably carry the instantaneous explosive torque of 1000cc upgraded motorcycles with a high safety factor.
530 Chain Motorcycle Detailed Specifications
| Technical parameters | Specifications/Description |
| Название продукта | 530 Chain Motorcycle |
| ANSI standard number | 50 / 530 |
| Pitch | 15,875 мм |
| Диаметр ролика | 10,16 мм |
| Внутренняя ширина | 9.53 mm |
| Диаметр штыря | 5,24 мм |
| Длина штыря | 22.60 mm (riveted type) |
| Inner/outer chain plate thickness | 2.40 mm / 2.40 mm |
| Average tensile strength | ≥ 42.0 kN (9440 lbs) |
| Maximum applicable displacement | up to 1000 cc |
| Вес на 100 секций | Approximately 2.15 kg |
| Color options | Original color, gold plating, nickel plating, black gold |
| Certification Standards | ISO 9001, JIS B 1801 |
530 Chain Motorcycle Applicable Crowd
Motorcycle Parts Wholesalers and Importers
Suitable for parts wholesalers focusing on the aftermarket. This product conforms to the international general 530 specifications, covers a wide range of models, and the cost-effective ex-factory price can reserve sufficient profit space for you in the distribution channels.
Motorcycle Maintenance Chain and Service Center
Suitable for repair shops that require high-quality replacement parts. The extremely stable quality of the Motomaxsfr chain can reduce the customer repair rate, and the simple riveting or hook installation method can significantly improve the technician’s repair efficiency.
Heavy Locomotive Refitting and Racing Club
It is suitable for the modification market with strict requirements on transmission performance. The high tensile strength and low resistance X-lap design meets the high-strength use requirements of track days or long-distance motorcycles, and is an ideal choice for performance upgrades.
Motorcycle complete vehicle manufacturing plant (OEM)
Suitable for medium and large motorcycle manufacturers looking for a reliable supply chain. We provide stable batch supply capacity and customized packaging services to ensure that the production line does not stop work, and enhance the quality of the vehicle factory reputation.
завод и сертификат
сертификат
Часто задаваемые вопросы и контакты
Добро пожаловать на страницу "Часто задаваемые вопросы". Мы собрали ответы на часто задаваемые вопросы, надеясь предоставить вам четкие и быстрые решения. Если вы не нашли здесь нужной информации, пожалуйста, свяжитесь с нашей службой поддержки.
Q1: What is the difference between 530 chain, 520 chain and 525 chain?
A1: The main difference is the roller width. The roller width of the 530 chain is 9.53mm, which is wider than the 520 and 525, so the contact area is larger, can withstand higher torque and tension, and is suitable for large-displacement motorcycles.
Q2: Does your 530 chain contain master links? What type is it?
A2: Yes, each chain comes with a matching master link. For 530 of these high-strength chains, we come standard with safer riveted joints, but we also provide snap-in joints for small displacements or temporary repairs.
Q3: What is the tensile strength of this chain? Can it be used for 1000cc motorcycles?
A3: The average tensile strength of the Motomaxsfr 530 chain exceeds 42kN (about 9440 pounds). It can fully meet the power transmission requirements of 1000cc or even larger displacement motorcycles, and the safety margin is sufficient.
Q4: As a wholesaler, can I customize the color and packaging of the chain?
A4: Certainly. We provide gold plating, nickel plating, paint and other color customization services. At the same time, we support OEM packaging design, you can print your brand Logo on the box and chain plate.
Q5:X-type sealing ring is really better than O-type sealing ring?
A5: Yes. The X-ring has four sealing lips, while the O-ring has only two. The X-ring not only has better sealing performance, but also has less distortion when compressed, and the frictional resistance generated is about 40% lower than that of the O-ring.
Q6: What is the minimum order quantity and delivery time for bulk purchase?
A6: For regular specifications, our MOQ is usually 100 pieces. The production and delivery cycle for regular orders is 20 to 30 days. If the products are in stock, they can be shipped within 3 days after confirming the order.
Пожалуйста, не стесняйтесь обращаться к нам. Мы с нетерпением ждем вашего ответа.
530 Chain Motorcycle Budget-friendly Choice
This 530 Chain Motorcycle is made of SCM420 chromium molybdenum alloy steel with an average tensile strength of more than 40 kN. It is specially designed to provide excellent fatigue resistance and wear resistance for large displacement locomotives above 400cc. Motomaxsfr is a source manufacturer with its own heat treatment workshop, strictly implementing ISO 9001 standards and eliminating traders, providing you with an absolute advantage of batch ex-factory quotation and highly flexible production scheduling.
15,875 мм
Pitch
9.53mm
Ширина ролика
more than 42 kN
Прочность на разрыв
530 Chain Motorcycle characteristics
4 riveting pin shaft technology
The unique four-sided riveting process is adopted to increase the flared diameter of the pin shaft head by 0.3mm, so that the thrust load bearing capacity of the chain link side plate is increased by 25%, and the risk of chain detachment under high-speed operation is effectively prevented.
Vacuum injection of solid lubricating oil
Before leaving the factory, high-viscosity and high-temperature resistant grease is injected through vacuum environment to ensure that the grease penetrates into the area of 100% of the clearance between pin shaft and sleeve. Compared with ordinary oil immersion process, the initial running-in wear of the chain is reduced by 60%.
Pre-stretch anti-fatigue treatment
Before leaving the factory, all chains are pre-stretched by 1/3 breaking load, which eliminates the initial inelastic deformation of the material, controls the initial elongation after loading within 0.1%, and greatly reduces the adjustment frequency.
High precision seamless sleeve
Abandon the rolled sleeve, the seamless sleeve formed by cold extrusion is adopted, and the cylindricity tolerance is controlled within 0.01mm to ensure smooth meshing with the sprocket and reduce the operating noise by 3 to 5 decibels.
X-ring long-lasting oil lock
Equipped with high-quality nitrile rubber X-ring, it uses four contact points to form a double sealing barrier. Compared with traditional O-ring, it can lock 40% more lubricating oil and block dirt from the outside.
Ultra wide displacement applicability
With extremely high tensile strength from 42kN to 46kN, the 530 chain is not only suitable for conventional 500cc models, but also can stably carry the instantaneous explosive torque of 1000cc upgraded motorcycles with a high safety factor.
530 Chain Motorcycle Detailed Specifications
| Technical parameters | Specifications/Description |
| Название продукта | 530 Chain Motorcycle |
| ANSI standard number | 50 / 530 |
| Pitch | 15,875 мм |
| Диаметр ролика | 10,16 мм |
| Внутренняя ширина | 9.53 mm |
| Диаметр штыря | 5,24 мм |
| Длина штыря | 22.60 mm (riveted type) |
| Inner/outer chain plate thickness | 2.40 mm / 2.40 mm |
| Average tensile strength | ≥ 42.0 kN (9440 lbs) |
| Maximum applicable displacement | up to 1000 cc |
| Вес на 100 секций | Approximately 2.15 kg |
| Color options | Original color, gold plating, nickel plating, black gold |
| Certification Standards | ISO 9001, JIS B 1801 |
530 Chain Motorcycle Applicable Crowd
Motorcycle Parts Wholesalers and Importers
Suitable for parts wholesalers focusing on the aftermarket. This product conforms to the international general 530 specifications, covers a wide range of models, and the cost-effective ex-factory price can reserve sufficient profit space for you in the distribution channels.
Motorcycle Maintenance Chain and Service Center
Suitable for repair shops that require high-quality replacement parts. The extremely stable quality of the Motomaxsfr chain can reduce the customer repair rate, and the simple riveting or hook installation method can significantly improve the technician’s repair efficiency.
Heavy Locomotive Refitting and Racing Club
It is suitable for the modification market with strict requirements on transmission performance. The high tensile strength and low resistance X-lap design meets the high-strength use requirements of track days or long-distance motorcycles, and is an ideal choice for performance upgrades.
Motorcycle complete vehicle manufacturing plant (OEM)
Suitable for medium and large motorcycle manufacturers looking for a reliable supply chain. We provide stable batch supply capacity and customized packaging services to ensure that the production line does not stop work, and enhance the quality of the vehicle factory reputation.
Узнайте нас и свяжитесь с нами
Получите бесплатный Цитировать Сегодня.
ЧАСТО ЗАДАВАЕМЫЕ ВОПРОСЫ
Q1: What is the difference between 530 chain, 520 chain and 525 chain?
A1: The main difference is the roller width. The roller width of the 530 chain is 9.53mm, which is wider than the 520 and 525, so the contact area is larger, can withstand higher torque and tension, and is suitable for large-displacement motorcycles.
Q2: Does your 530 chain contain master links? What type is it?
A2: Yes, each chain comes with a matching master link. For 530 of these high-strength chains, we come standard with safer riveted joints, but we also provide snap-in joints for small displacements or temporary repairs.
Q3: What is the tensile strength of this chain? Can it be used for 1000cc motorcycles?
A3: The average tensile strength of the Motomaxsfr 530 chain exceeds 42kN (about 9440 pounds). It can fully meet the power transmission requirements of 1000cc or even larger displacement motorcycles, and the safety margin is sufficient.
Q4: As a wholesaler, can I customize the color and packaging of the chain?
A4: Certainly. We provide gold plating, nickel plating, paint and other color customization services. At the same time, we support OEM packaging design, you can print your brand Logo on the box and chain plate.
Q5:X-type sealing ring is really better than O-type sealing ring?
A5: Yes. The X-ring has four sealing lips, while the O-ring has only two. The X-ring not only has better sealing performance, but also has less distortion when compressed, and the frictional resistance generated is about 40% lower than that of the O-ring.
Q6: What is the minimum order quantity and delivery time for bulk purchase?
A6: For regular specifications, our MOQ is usually 100 pieces. The production and delivery cycle for regular orders is 20 to 30 days. If the products are in stock, they can be shipped within 3 days after confirming the order.
